A15
Achromic Series 15-inch, 2-way Active Loudspeaker. Built-in Digital Signal Processing (DSP) with LCD screen, EQ multiple presets.
A15
Avante Audio A15
Specifications
• Amp Power: 1200W Peak; 350W Class D (LF) + 50W Class AB (HF) RMS
• Built-in Digital Signal Processing (DSP) with LCD screen, EQ multiple presets
• Frequency Range: 45hz-20kHz
• Nominal Coverage: 90˚ x 60˚
• Output (Peak SPL @ 1M): 124dB
• Drivers: 15-inch woofer with 2.5-inch voice coil + 1.35-inch HF Compression Driver
• Inputs: Balanced Female XLR ¼-inch combo jack, 2x RCA (phono)
• Output: Balanced Male XLR
• Enclosures: H-PP Molded
• Grill: 1.2mm Steel
• Handles: 1 on top / 1 on side
• Fly Points: 2 on top / 1 on back
• Pole Mounting: Dual position 0-degrees or 7.5-degrees
• Power Input: 120V/60Hz or 240V/50Hz (country specific)
• Power Consumption: 400W
• Dimensions: 28.7”x16.7”x16.3” / 728x425x414mm
• Weight: 42 lbs. / 19.1 kg.
Downloads
| Filename | Document type | File type |
|---|---|---|
| Avante Achromic Speaker Frequency Charts | Frequency Charts | |
| Avante Achromic Series Cut Sheets | Cut Sheet | |
| Avante Achromic Speaker Technical Specifications | Specification Sheet | |
| Avante Achromic Speaker Dimensions | Dimensional Drawings | |
| ACHROMIC Series Speakers User Manual | User Manual |
A15 Parts & Service
Our A15 Parts and Support page is your hub for technical support for your product. Here you’ll find replacement parts specifically matched to your A15. You can also use this area to plan future maintenance, extending the life of your investment and minimizing downtime.
A15 Parts
