240W RMS Class D Power Amplifier with dual 4.75" woofers. Part of the Imperio Mini Line Array Series.

UPC: 818651025477SKU: IMP092

Related Products

IMPERIO

Avante Imperio

Avante Audio’s Imperio mini line array system is a great fit for small to mid-size venues. The Imperio system consists of the Imperio Sub, a 10-inch, 400W Subwoofer with a Class D digital amplifier, and the Imperio, a cabinet with dual 4.75-inch woofers, a 240W Class D power amplifier and 24-bit DSP. The system may be configured in a variety of ways with multiple Imperio Subs and 8 Imperio cabinets linked together with the sub on top or bottom. All items including the flybar are sold separately to allow for maximum customizability and versatility.

Imperio accessories include; Imperio Flybar LG (IMP265), Imperio Flybar Small (IMP496), Imperio Pole (IMP194) and Linkpin 2 (IMP340).

Specifications

AMPLIFIER:

• 240W Class RMS D Amplifier Module

• Switching Power Design

• LED Power / Signal / Clip Indicator

• 24-bit DSP Selectable Configurations

• Input: 1x 3pin XLR and Locking Power Connector

• Output: 1x 3pin XLR and Locking Power Connector

• Volume: Selectable Input Sensitivity Dial

• Power Input: 100-240V ~ 50/60Hz


SPEAKER:

• 2x 4.75" Neodymium Woofer with 1-inch voice coil

• 6x 1.75" IDVAT HF drivers (Inverted Dome Vertical Array Technology)

• Type: 2-Way Active Closed Design

• Frequency Response: 150Hz – 20KHz

• Impedance: 4 Ohm

• Max Output SPL: 117dB (single box measured on Axis @1m)

• Selectable Input Sensitivity: -3dB, 0dB, 3dB, 6dB

• Cabinet: ABS Plastic

• Grill: 1.0mm steel

• Splay Angles: 0, 4, 8, 12-degrees

• Integrated Rigging: Yes

• Dispersion Angle: 90-degree x 15-degree

• Dimensions (HxWxD): 12.8"x7.3"x8.8" / 324x184.8x224mm

• Weight: 14 lbs. / 6.3 kg.

Downloads

Filename Document type File type
IMPERIO Frequency Chart Configuration 4 Frequency Charts PDF
IMPERIO Frequency Chart Configuration 2 Frequency Charts PDF
IMPERIO Frequency Chart Configuration 7 Frequency Charts PDF
Imperio User Manual User Manual PDF
IMPERIO Frequency Chart Configuration 3 Frequency Charts PDF
IMPERIO Frequency Chart Configuration 5 Frequency Charts PDF
IMPERIO Frequency Chart Configuration 8 Frequency Charts PDF
IMPERIO Frequency Chart Configuration 6 Frequency Charts PDF
IMPERIO Frequency Chart Configuration 1 Frequency Charts PDF

IMPERIO Parts & Service

Our IMPERIO Parts and Support page is your hub for technical support for your product. Here you’ll find replacement parts specifically matched to your IMPERIO. You can also use this area to plan future maintenance, extending the life of your investment and minimizing downtime.
